- Customised Test Contactor with Pitch sizes ≥ 0.25 mm
- Manual or automated applications
- Contact force (typical) between 15 g to 35 g
Features
Advantages
- Outstanding performance
- HF capable
- Kelvin & non-kelvin solutions
- For any application like, failure analysis, ATE and silicon validation
Specifications
General Specification
- Mating Cycles
500,000 - Operating Temperature Range
-55 °C – 150 °C
Electrical Specification
- (Initial) Contact Resistance
50 Milliohm - Current Rating
1.2 A
Interface Specification
- Pitch
0.25
